ISDT P30

ISDT P30

SPECIFICATIONS

• Input voltage: DC 10~34V
• Output voltage: DC 1~34V
• Max. input current: 60A
• Charging current: 0.2~30A x2
• Discharging current: 0.2~3.0A x2
• Working temperature: 0°C~40°C
• Storage temperature: -20°C~60°C
• Abnormal voltage alarm: Support
• Incorrect cell count setting alarm: Support
• Dimension: 110x110x65mm
• Weight: 730g
• Balance current: 1.5A/Cell Max
• Max. discharging power: 30W x2
• Max. charging power:
• Single channel Max. 1000W
• Whole model Max. 1500W
• Supported battery types and cell count:
• LiFe
• LiIon
• LiPo 1-8S
• LiHv 1-7S
• Pb 1-12S
• NiMH/Cd 1-16S
